30
②②
WATER SUPPLY FUNCTION
▶
It is an operation that water is supplied to the ice tray using a solenoid valve connected directly to the water line
when ice ejection is completed.
1) When the ejection arm is in the horizontal state and the completion of the ejection operation, operate the
water solenoid valve with a Time check function to supply water to the ice tray.
2) Once it is supplied with water, it waits for at least 46 minutes and when the temperature of the ice maker
sensor remains below 18.5℉ for 41℉ seconds, it carries out the normal ejection and supplies water again.
3) Water is to be supplied regardless of the F/R-Door opening.
③③
ICE PRODUCTION FUNCTION
▶
The water in the ice tray is judged as completely frozen after the completion of water supply operation. Ice
making will be terminated by the temperature of the ice maker sensor.
1) When the ice maker sensor is maintained lower than18.5℉ for 5 seconds, it will be evaluated as the
completion of ice making.
It will not check the ice maker sensor within 46 minutes from the water filling. (Safety function for cold air
leak or sensor error)
2) It will check the temperature from the ice maker after the water filling.
It will not carry out the ejection even though the temperature goes down below 18.5℉
3) If the temperature of the ice maker sensor is maintained below 18.5℉ for more than 5 seconds, it carries
out the ice ejection.
④④
EJECTION FUNCTION
▶ After completion of ice making, the operation of ice separation from the ice tray will be carried out.
1) To separate ice from the ice tray, ejection arm will be rotated by rotating the Eject Motor clockwise.
2) When the ejection arm is restored to the horizontal position the operation of ice separation from the ice tray
finishes.
3) If the detection of ice bin is full, the operation of ice separation from the ice tray will not be carried out.
⑤⑤
TEST FUNCTION
▶
To operate manually the ice maker, move the feeler arm up and down three times in 16 seconds after initial
power on.
1) When moving the feeler arm up and down three times in 16 seconds after initial power on, the Ice eject
motor will rotate ejecting ice regardless of the elapsed time of 46 minutes and the ice making temperature.
Then it will be restored to the horizontal position and supply water to the ice tray.
2) Operate normally regardless of the F,R-door opening.
⑥⑥
OPERATING ERROR
▶ When the ice maker dose not operate properly, the LED blinks continuously.
1) Turn the ice maker power switch on and off.
2) If the ice cubes stuck in ice maker, turn off the ice maker and remove cubes and turn the ice maker back on.
Ice Dispenser function stops working when the F-Door is open. If the ice dispenser is operated when
the F-Door is open, the ice falls on the floor, the water dispenser operates normally regardless of the
door opening.
Note
