The descriptions of internal parts are illustrated in the photo below and refer to the pages below for disassembling each
part. For the parts not illustrated in the photo, refer to the exploded view.
❶ Ice Storage Bin 48
❷ Winter Closet 49
❸ F-Room Lamp 51
❹ Ice Chute
❺ F-Room Shelf 48
❻ F-Room Utility Bin
❼ Dry Room/ Meat Drawer 48
❽ R-Room Shelf 48
NO Description Page
❾ R-Room Lamp 53
❿ Veg/Fruit Drawer 48
Fresh Island 52
Dairy Bin 48
R-Room Utility Bin
Grille Panel 54
NO Description Page
6-2-2. Interior Overview
Make sure to turn it off before disassembly. Risk of electric shock.
