USER'SMANUALOFEMBEDDEDDIGITALVIDEORECORDER

Page 9 of 27

D6010DH8/D6011FH8/D6012WH8：



1.VIDEOIN:Videoinputinterface8.NET:RJ‐45networkinterface

2.AUDIOOUT:Audiooutputinterface9.USB:USBinterface



3.AUDIOIN:Audioinputinterface(1‐2)10.RS‐485:RS‐485interface

4.Alarm:Alarminput/outputinterface11.DC12:12V(DC)PowerSupplyConnector

5.VIDEOOUT:BNCvideooutputinterface12.AUDIOIN:Audioinputinterface(3‐8)

6.POWERSwitch：MainPowerSwitch13.HDMI：HDMIOutputConnector

VGA:VGAoutputinterface



D7010DH16/D7011DH16/D7012FH16：



1.VIDEOIN：VideoInputConnector7.AUDIOOUT:Audiooutputinterface

2.VIDEOOUT：VideoOutputConnector8.VGA:VGAoutputinterface

3.AUDIOIN：AUDIOInputConnector(1‐2)9.NET：RJ‐45StandardNetworkConnector

4.HDMI：VideoOutputConnector10.USB：StandardUSBConnector

5.Alarm:Alarm

inputinterface11.R485：485Pan/TileDeviceConnector

6.POWER:Powerkey(RESERVE)12.DC12V：12V(DC)PowerSupplyConnector

13.AUDIOIN：AUDIOInputConnector(3‐8)



D8001CH24：



1.VIDEOIN：VideoInputConnector7.Alarm:Alarminputinterface

2.AUDIOIN：AUDIOInputConnector(1‐8)8.HDMI：VideoOutputConnectorinterface
