Definox DCX3 User Manual

MAINTENANCE NOTICE
NM-230 index 18 Page 46/55 September 2020
9.8 LIST OF ACTUATORS FOR DCX3 AUTOMATIC CHANGEOVER VALVES
Guide Part name Qty
DN25/40 DN50/51 DN63/76 DN80
DN80
ACT. 104
DN104
80
Standard
DCX3
valve actuator, elastomer &
diaphragm
1
7100300 7100301 7100302 7100303
81
DCX3 aseptic seat valve actuator
1
7100487 7100488 7100489 7100490
9.9 LIST OF REFERENCES OF SEAL KITS FOR DCX3/4 AUTOMATIC VALVES.
DESCRIPTION DN 25-40 DN 50-51 DN 63-76 DN 80
DN80
ACT
.104
DN 100-
104
For details of kit
A
see following chapter
1
Actuator seal kit for DCX3 standard valve
7070600 7070601 7070602 7070603
2 Actuator seal kit for DCX3 aseptic seat valve 7070536 7070537 7070538 7070539
For details of kit
B
see following chapter
1
EPDM FDA seal kit for DCX3 standard valve
7070612 7070613 7070614 7070615
2
FKM FDA seal kit for DCX3 standard valve
7070616 7070617 7070618 7070619
3
VQM FDA seal kit for DCX3 standard valve
7070620 7070621 7070622 7070623
For details of kit
C
see following chapter
1
EPDM FDA seal kit for DCX3 elastomer seal valve
7070566 7070567 7070568 7071004 7070569 7070570
2
FKM FDA seal kit for DCX3 elastomer seal valve
7070571 7070572 7070573 7071005 7070574 7070575
3
VMQ FDA seal kit for DCX3 elastomer seal valve
7070576 7070577 7070578 7071006 7070579 7070580
For details of kit
D
see following chapter
1
Diaphragm/EPDM seal Kit for DCX3 diaphragm valve
7071022 7071023 7071024 7071025 7071026
2
Diaphragm/FKM seal kit for DCX3 diaphragm valve
7071027 7071028 7071029 7071030 7071031
3
Diaphragm/VMQ seal kit for DCX3 diaphragm valve
7071032 7071033 7071034 7071035 7071036
For details of kit
E
see following chapter
1
EPDM FDA seal kit for DCX3 aseptic seat valve
7071052 7071053 7071054 7071055 7071056
2
FKM FDA seal kit for DCX3 aseptic seat valve
7071057 7071058 7071059 7071060 7071061
3
VMQ FDA seal kit for DCX3 aseptic seat valve
7071062 7071063 7071064 7071065 7071066
For details of kit
F
see following chapter
1
Diaphragm/EPDM FDA seal kit for DCX3 elastomer
diaphragm valve
7071037 7071038 7071039 7071040 7071069 7071041
2
Diaphragm/FKM FDA seal kit for DCX3 elastomer
diaphragm valve
7071042 7071043 7071044 7071045 7071070 7071046
3
Diaphragm/VMQ FDA seal kit for DCX3 elastomer
diaphragm valve
7071047 7071048 7071049 7071050 7071071 7071051
For details of kit
G
see following chapter
1
EPDM FDA seal kit for DCX3 aseptic seat valve with
elastomer plug
7071072 7071073 7071074 7071075 7071076 7071077
2
FKM FDA seal kit for DCX3 aseptic seat valve with
elastomer plug
7071078 7071079 7071080 7071081 7071082 7071083
3
VMQ FDA seal kit for DCX3 aseptic seat valve with
elastomer plug
7071084 7071085 7071086 7071087 7071088 7071089
