Definox DCX3 User Manual

MAINTENANCE NOTICE
NM-230 index 18 Page 48/55 September 2020
EPDM FDA seal kits for DCX3 standard valve :
B1
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7070612 7070613 7070614 7070615
Guide Part name Qty Seal reference
20
Seal support plate O-ring
EPDM FDA
1 7380158 7380159 7006164 7006183
25
Seal support plate O-ring
EPDM FDA
1 7380137 7380179 7006160
26
Internal support plate ring
2 7009993 7009972 7009973
27
Scraper seal
1 7006147 7006030 7006034
FKM FDA seal kits for DCX3 standard valve :
B2
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7070616 7070617 7070618 7070619
Guide Part name Qty Seal reference
20
Seal support plate O-ring FKM
FDA
1 7380607 7010801 7010810 7006063
25
Seal support plate O-ring FKM
FDA
1 7006157 7380899 7380617
26
Internal support plate ring
2 7009993 7009972 7009973
27
Scraper seal
1 7006147 7006030 7006034
VMQ FDA seal kits for DCX3 standard valve :
B3
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN DN80 ACT. 104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7070620 7070621 7070622 7070623
Guide Part name Qty Seal reference
20
Seal support plate O-ring. VMQ
FDA
1 7006171 7006175 7006180 7006184
25
Seal support plate O-ring. VMQ
FDA
1 7006170 7006035 7006589
26
Internal support plate ring
2 7009993 7009972 7009973
27
Scraper seal
1 7006147 7006030 7006034
