Definox DCX3 User Manual

MAINTENANCE NOTICE
NM-230 index 18 Page 52/55 September 2020
EPDM FDA seal kits for DCX3 diaphragm valve with elastomer plug :
F1
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7071037 7071038 7071039 7071040 7071069 7071041
Guide Part name Qty Seal reference
23
O-ring for seal support plate with leak
collector EPDM FDA
1 7006145 7006038 7006235 7006008
24
DCX3/4 plug O-ring EPDM FDA
1 7006174 7380158 7006193 7006002 7006008 7006162
32
Diaphragm PTFE
1 7006691 7006692 7006693 7006694
33
Spring washer
2 7007425 7007419 7007426
34
Diaphragm seal support plate ring
1 7003558 7009962 7009988 7010166
FKM FDA seal kits for DCX3 diaphragm valve with elastomer plug :
F2
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7071042 7071043 7071044 7071045 7071070 7071046
Guide Part name Qty Seal reference
23
O-ring for seal support plate with leak
collector FKM FDA
1 7380624 7006128 7010801 7380606
24
DCX3/4 plug O-ring FKM FDA
1 7006173 7380607 7380609 7380601 7380606 7006136
32
Diaphragm PTFE
1 7006691 7006692 7006693 7006694
33
Spring washer
2 7007425 7007419 7007426
34
Diaphragm seal support plate ring
1 7003558 7009962 7009988 7010166
VMQ FDA seal kits for DCX3 diaphragm valve with elastomer plug :
F3
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7071047 7071048 7071049 7071050 7071071 7071051
Guide Part name Qty Seal reference
23
O-ring for seal support plate with leak
collector VMQ FDA
1 7006204 7006036 7006152 7006226
24
DCX3/4 plug O-ring VMQ FDA
1 7006172 7006171 7006057 7006181 7006083 7006198
32
Diaphragm PTFE
1 7006691 7006692 7006693 7006694
33
Spring washer
2 7007425 7007419 7007426
34
Diaphragm seal support plate ring
1 7003558 7009962 7009988 7010166
