Definox DCX3 User Manual

MAINTENANCE NOTICE
NM-230 index 18 Page 53/55 September 2020
EPDM FDA seal kits for DCX3 aseptic seat valves with elastomer plugs :
G1
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7071072 7071073 7071074 7071075 7071076 7071077
Guide Part name Qty Seal reference
15
Seal support plate O-ring EPDM
FDA
1 7006145 7006038 7006441
20
Seal support plate O-ring EPDM
FDA
1 7380158 7380159 7006164 7006183
24
Elastomer plug O-ring EPDM FDA
1 7006174 7380158 7006193 7006002 7006008 7006162
25
Seal support plate O-ring EPDM
FDA
1 7380137 7380179 7006160
26
Internal support plate ring
1 7009993 7009972 7009973
FKM FDA seal kits for DCX3 aseptic seat valves with elastomer plugs:
G2
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7071078 7071079 7071080 7071081 7071082 7071083
Guide Part name Qty Seal reference
15
Seal support plate O-ring EPDM
FDA
1 7006145 7006038 7006441
20
Seal support plate O-ring FKM FDA
1 7380607 7010801 7010810 7006063
24
Elastomer plug O-ring FKM FDA
1 7006173 7380607 7380609 7380601 7380606 7006136
25
Seal support plate O-ring EPDM
FDA
1 7006157 7380899 7380617
26
Internal support plate ring
1 7009993 7009972 7009973
VMQ FDA seal kits for DCX3 aseptic seat valves with elastomer plugs:
G3
Diameter
DN25-38 SMS DN51 SMS DN63-76 SMS
DN80 DIN
DN80 ACT.
104
104 SMS
100 DIN
DN25-40 DIN DN50 DIN DN65 DIN
DN1’’-1’’1-2 US DN2’’ US DN3’’ US DN4’’ US
Kit No.: 7071084 7071085 7071086 7071087 7071088 7071089
Guide Part name Qty Seal reference
15
Seal support plate O-ring EPDM
FDA
1 7006145 7006038 7006038 7006441
20
Seal support plate O-ring. VMQ FDA
1 7006171 7006175 7006180 7006184
24
Elastomer plug O-ring VMQ FDA
1 7006172 7006171 7006057 7006181 7006083 7006198
25
Seal support plate O-ring EPDM
FDA
1 7006170 7006035 7006589
26
Internal support plate ring
1 7009993 7009972 7009973
