PPM Installation Instructions
DEIF A/S Page 11 of 69
Option EF2
Analogue speed governor output and one transducer output.
Term. Function Description
65 Not used
66 +/-20 mA Speed governor setpoint output
67 0
68 Not used
69 Not used
70 0(4) - 20 mA out Analogue output 3
71 0
72 Not used
These outputs are active outputs, meaning that they have an internal power supply. The outputs
are galvanically separated from each other and from the rest of the unit. Via the display or the
PC programming software individual outputs can be selected to represent any AC measuring
value and related values e.g. power, power factor, frequency etc. Outputs can be selected to be
either 0…20 mA or 4…20 mA in the PC utility software. If necessary, the current outputs can be
converted to voltage using a resistor across the terminals (500 will convert the 0-20 mA into 0-
10V DC).
