PPM Installation Instructions
DEIF A/S Page 51 of 69
Option M18
4 x relay outputs.
Term. Function Description
90 Relay output 14
250V AC, 8A max.
Configurable
91
92 Relay output 15
250V AC, 8A max.
Configurable
93
94 Relay output 16
250V AC, 8A max.
Configurable
95
96 Relay output 17
250V AC, 8A max.
Configurable
97
Slot #7, not used
Slot #8, internal communication
Term. Function Description
126 Not used CANbus communication line between the units
For internal use only!
127 Not used
128 Can-L
129 Not used
130 Can-H
131 Can-L
132 Not used
133 Can-H
