Deif PPU - Page 52

PPM Installation Instructions
DEIF A/S Page 52 of 69
Binary inputs
Term. Name Function
23 Configurable. User-programmable This input is programmable from the PC utility software.
24 Configurable. User-programmable Trip of breaker due to short circuit protection from
external device.
25 Configurable. User-programmable This input is programmable from the PC utility software.
26 Configurable. User-programmable This input is programmable from the PC utility software.
27 PMS control The unit is selected to be in power management control
or in switchboard control.
43 Configurable. User-programmable These inputs are programmable from the PC utility
software.
44 Configurable. User-programmable
45 Configurable. User-programmable
46 Configurable. User-programmable
47 Configurable. User-programmable
48 Configurable. User-programmable
49 Configurable. User-programmable
50 Alarm Inhibit 1/configurable External input for inhibit of selected alarms/configurable.
51 Alarm Inhibit 2/configurable External input for inhibit of selected alarms/configurable
52 Configurable. User-programmable These inputs are programmable from the PC utility
software.
53 Configurable. User-programmable
54 CB open Breaker feedback signal. The connection breaker is in
position ON.
55 CB closed Breaker feedback signal. The connection breaker is in
position OFF.
