6a SAS 12 Gbps 4 online
6b SAS offline
6c SAS 24 Gbps 3 online
6d SAS offline
9a SAS offline
9b SAS offline
9c SAS offline
9d SAS 24 Gbps 2 online
---- ---------- ------- ------------- -------
The output shows:
l
The online status for each SAS connection, such as 2a, 3a, 6a
l
The offline status for each SAS connection, such as 2b, 3b, 6b
l
After the shelves have been connected, the same command also displays the
connected enclosure IDs for each port. The status changes to online.
2. After adding any enclosure/shelf, enter the disk show state command to
verify the disk state.
# disk show state
Enclosure Disk
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
--------- ----------------------------------------------
1 . . . .
2 U U U U U U U U U U U U U U U
3 s U U U U U U U U U U U U U F
4 U U U U U U U U U U U U U U U
5 A K v K K K K K K v K K K K R
--------- ----------------------------------------------
Legend State Count
------ ---------------------------- -----
. In Use Disks 4
s Spare Disks 1
R Spare (reconstructing) Disks 1
v Available Disks 2
K Known Disks 11
U Unknown Disks 43
F Failed Disks 1
A Absent Disks 1
------ ---------------------------- -----
Total 64 disks
Run the storage add command to add disks in the U state to the Data
Domain system.
3. Verify that the Data Domain system recognizes each attached enclosure/shelf
by entering the enclosure show summary command:
# enclosure show summary
Enclosure Model No. Serial No. State OEM OEM Capacity
Name Value
-------- --------- -------------- ------ ------ ------- --------
1 DD9500 NVT10133200020 Online 4 Slots
2 ES30 APM00133825711 Online 15 Slots
3 ES30 APM00120900626 Online 15 Slots
4 ES30 APM00123706119 Online 15 Slots
5 ES30 APM00133825239 Online 15 Slots
-------- --------- -------------- ------ ------ ------- ---------
5 enclosures present.
Post-Installation Tasks
124 Data Domain ES30 Expansion Shelf and FS15 SSD Shelf Hardware Guide
