Table 10 Shelf configuration supported per Data Domain system (continued)
DD system Memory
required
(GB)
SAS
cards/
port per
card
ES30
support
(TB)
ES20
support
(TB)
1
Max
shelves
per set
Max
number
of sets
Max external
capacity
available
(TB)
2
Max RAW
external
capacity
(TB)
8
DD9500 256 3x4 SAS 30,
45, 60;
SATA 15,
30, 45
5
N/A
11
5
6
6 432 540
DD9500 512 3x4 SAS 30,
45, 60;
SATA 15,
30, 45
5
N/A
11
5
6
6 864 1080
DD9500 ER
4, 7
512 4x4 SAS 30,
45, 60;
SATA 15,
30, 45
5
N/A
11
7 8 1728 2160
DD9500 HA
9, 10
256 3x4 SAS 30,
45, 60
N/A
11
5
6
6 432 540
DD9500 HA
9, 10
512 3x4 SAS 30,
45, 60
N/A
11
5
6
6 864 1080
DD9500 w/ DD
Cloud Tier
13
512 4x4 SAS 30,
45, 60;
SATA 15,
30, 45
N/A
11
7 8 864 (max),
additional 240
SAS dedicated
to DD Cloud
Tier
1080 (max),
additional
300 SAS
dedicated to
DD Cloud Tier
DD9500 w/ HA
and DD Cloud
Tier
13
512 4x4 SAS 30,
45, 60
N/A
11
7 8 864 (max),
additional 240
SAS dedicated
to DD Cloud
Tier
1080 (max),
additional
300 SAS
dedicated to
DD Cloud Tier
DD9800
13
256 3x4 SAS 30,
45, 60;
SATA 15,
30, 45
N/A
11
5 6 504 630
DD9800 w/ HA
13
256 3x4 SAS 30,
45, 60
N/A
11
5 6 504 630
DD9800
12, 13
768 3x4 SAS 30,
45, 60;
SATA 15,
30, 45
N/A
11
5 6 1008 1260
DD9800 w/ HA
13
768 3x4 SAS 30,
45, 60
N/A
11
5 6 1008 1260
DD9800 w/ ER
13
768 4x4 SAS 30,
45, 60;
SATA 15,
30, 45
N/A
11
7 8 2016 2520
Installing the Shelves
26 Data Domain ES30 Expansion Shelf and FS15 SSD Shelf Hardware Guide
