Table 21 DD4200 cabling information
DD4200
ES20 ES20 chains ES30 SATA ES30 SATA
chains
ES30 SAS ES30 SAS
chains
13-16 4 0 0 0 0
9-12 3 1-5 1 0 0
9-12 3 0 0 1-3 1
5-8 2 6-10 2 0 0
5-8 2 1-5 1 1-5 1
5-8 2 0 0 5 2
5-8 2 0 0 1-4 1
1-4 1 8-12 3 0 0
1-4 1 6-10 2 1-5 1
1-4 1 1-5 1 1-4 1
1-4 1 1-5 1 5-7 2
1-4 1 0 0 1-4 1
1-4 1 0 0 5-7 2
0 0 13-16 4 0 0
0 0 9-12 3 1-3 1
0 0 5-8 2 1-4 1
0 0 5-8 2 5 2
0 0 1-4 1 1-4 1
0 0 1-4 1 5-7 2
0 0 0 0 1-4 1
0 0 0 0 5-8 2
Table 22 DD4500 cabling information
DD4500
ES20 ES20 chains ES30 SATA ES30 SATA
chains
ES30 SAS ES30 SAS
chains
13-16 4 0 0 0 0
9-12 3 1-5 1 0 0
9-12 3 0 0 1-5 1
5-8 2 1-5 1 1-5 1
5-8 2 6-8 2 0 0
5-8 2 0 0 1-5 1
Installing the Shelves
46 Data Domain ES30 Expansion Shelf and FS15 SSD Shelf Hardware Guide
