Table 22 DD4500 cabling information (continued)
DD4500
5-8 2 0 0 6-10 2
1-4 1 9-12 3 0 0
1-4 1 5-8 2 1-5 1
1-4 1 1-4 1 1-5 1
1-4 1 1-4 1 6-10 2
1-4 1 0 0 1-4 1
1-4 1 0 0 5-8 2
1-4 1 0 0 9-11 3
0 0 16-21 4 0 0
0 0 11-15 3 1-5 1
0 0 6-10 2 1-4 1
0 0 6-10 2 5-9 2
0 0 1-5 1 1-4 1
0 0 1-5 1 5-8 2
0 0 1-5 1 9-11 3
0 0 0 0 1-4 1
0 0 0 0 5-8 2
0 0 0 0 9-12 3
Table 23 DD7200 cabling information
DD7200
ES20 ES20 chains ES30 SATA ES30 SATA
chains
ES30 SAS ES30 SAS
chains
13-16 4 0 0 0 0
9-12 3 1-5 1 0 0
9-12 3 0 0 1-5 1
5-8 2 1-5 1 1-5 1
5-8 2 6-8 2 0 0
5-8 2 0 0 1-5 1
5-8 2 0 0 6-10 2
1-4 1 11-15 3 0 0
1-4 1 6-10 2 1-5 1
1-4 1 1-5 1 1-5 1
1-4 1 1-5 1 6-10 2
Installing the Shelves
DD4200, DD4500, and DD7200 cabling 47
