Table 9 D-Series configurations
Model number Nodes DAEs Disks in each
DAE
Disk Size Storage
capacity
Switches
D4500 8 8 70 8TB 4.5 PB One private and two
public
D5600 8 8 70 10TB 5.6 PB One private and two
public
D6200 8 8 98 8TB 6.2 PB One private and two
public
D7800 8 8 98 10TB 7.8 PB One private and two
public
D-Series upgrade paths
The D-Series Appliances can be upgraded as shown in the table.
Table 10 D-Series upgrades
Upgrade option
name
Number
of disks
Hardwa
re
Description
224 8 TB Disk
Upgrade Kit
(upgrades D4500 to
D6200)
224 16 Sleds Adds 2 sleds of 14 disks each (28 disks total) to
each DAE.
224 10 TB Disk
Upgrade Kit
(upgrades D5600 to
D7800)
224 16 Sleds Adds 2 sleds of 14 disks each (28 disks total) to
each DAE.
C-Series Appliance (Gen2) configurations and upgrade
paths
Describes the second generation C-Series ECS Appliance configurations and the
upgrade paths between the configurations. Gen2 hardware became generally available
in February 2016.
C-Series (Gen2) configurations
The C-Series Appliance is a dense compute solution using commodity hardware.
Table 11
C-Series (Gen2) configurations
Phoenix-12
Compute Servers
Nodes Storage
capacity
Switches
2 (minimum
configuration)
8 144TB One private and two public
3 12 216TB One private and two public
4 16 288TB One private and two public
Hardware Components and Configurations
20 D- and U-Series Hardware Guide
