Table 7. Chassis physical design
Parameter Specifications
Height 5.2 cm (2.0 in)
Width 20.8 cm (8.1 in)
Depth 20.0 cm (7.9 in)
Chassis weight with factory-installed components
NOTE: Chassis weight does not include the weight of the
power supply.
• 4-core: 1.44 kg (3.17 lb)
• 8-core: 1.42 kg (3.13 lb)
• 16-core: 1.44 kg (3.17 lb)
Table 8. Environmental parameters
Parameter Specifications
Operating temperature 0–40°C (32°F–104°F) continuously
Operating humidity
• 5% to 85% (RH), noncondensing continuously
• 5% to 90% (RH), noncondensing short-term (< 1% of
operational hour per year)
Storage temperature –40°-70°C (–40° to 158°F)
Storage humidity
• 5% to 90% (RH), noncondensing
Maximum operational altitude 3,048 meters (10,000 ft) with no performance degradation to 950
meters (3117 ft)
Maximum nonoperational altitude 10,668 meters (35,000 ft)
Table 9. AC power requirements
Parameter Specifications
Power supply 100–240 VAC 50/60 Hz
Maximum current draw per system - AC
• 100 VAC: 1.4A
• 240 VAC: 0.6A
Power consumption Typical:
• 40 W (16 core)
• 35 W (8 core)
• 20 W (4 core)
Maximum:
• 50 W (16 core)
• 45 W (8 core)
• 30 W (4 core)
NOTE: For the most current AC power requirements and power consumption specifications, see the Installation Guide
at https://www.dell.com/support
Introduction 7
