Dell 1350CNW - Rear View; Space Requirements

26 About the Printer
Rear View
Space Requirements
Place the printer at a location such that there is adequate space for using the
printer feeder and covers.
1 Wall Jack Connector 2 Rear Cover Release Handle
3 USB Port 4 Ethernet Port
5 Security Slot 6 Rear Cover
7 Transfer Roller 8 Paper Chute
9 Paper Feed Roller 10 Trans fer Belt
11 Fuser Release Lever
1
6
7
8
9
10
11
2
3
4
5
