If you are loading A6-size paper:
a Squeeze and slide the length guide toward the center of the tray to the A5 size position.
b Raise the A6 backstop.
Notes:
• The standard tray accommodates only 150 sheets of A6-size paper. Notice the maximum fill line on the A6
backstop which indicates the maximum height for loading A6-size paper. Do not try to overload the tray.
• A6-size paper cannot be loaded in the optional tray.
Note: Use the size indicators on the bottom of the tray to help position the guide.
3 Flex a stack of paper back and forth to loosen the sheets, and then fan them. Do not fold or crease the paper.
Straighten the edges on a level surface.
4 Load the paper stack toward the back of the tray as shown with the recommended print side facedown.
Note: The maximum fill line on the width guide indicates the maximum height for loading paper. Do not load
A6-size paper to the maximum fill line; the tray holds only 150 sheets of A6-size paper.
Loading paper and specialty media
78
