CHAPTER 4: HARD DRIVE(S)
Remove the four screws that secure the hard drive bracket to the hard drive.7.
Slide the hard drive out of the hard drive bracket.8.
1
3
2
1 hard drive 3 screws (4)
2 hard drive bracket
Remove the interposer from the hard drive, if applicable.9.
1
2
1 interposer 2 hard drive
