CHAPTER 10: PALM REST
Replacing the Palm Rest
Follow the instructions in “Before You Begin” on page 1. 6.
Slide the touch pad cable into the touch pad connector and push the tabs 2.
on the touch pad connector to secure the cable.
Align the tabs on the palm rest with the slots on the computer.3.
Slide the palm rest into position.4.
Turn the computer over and replace the three screws that secure the palm 5.
rest to the computer base.
Replace the battery pack (see “Replacing the Battery Pack” on page 6. 11).
CAUTION: Before turning on the computer, replace all screws and ensure
that no stray screws remain inside the computer. Failure to do so may
result in damage to the computer.
