Keyboard-controller board
Removing the keyboard-controller board
Prerequisites
1. Follow the procedure in
Before working inside your computer.
2. Remove the base cover.
3. Remove the
battery.
About this task
The following image(s) indicate the location of the keyboard-controller board and provides a visual representation of the removal
procedure.
NOTE: For models shipped with a per-key or mechanical keyboard, the computer will require a keyboard language and
keyboard color setup after keyboard-controller board is replaced. When the computer is reassembled and powered on, an error
message will be displayed. Press F2 to go to the Keyboard section of the BIOS Setup Utility to set up the keyboard language
and keyboard color.
41
