Steps
1. Using the alignment posts, place the battery on the palm-rest and keyboard assembly.
2. Align the screw holes on the battery with the screw holes on the palm-rest and keyboard assembly.
3. Replace the four screws (M2x4) that secure the battery to the palm-rest and keyboard assembly.
4. Adhere the tape that secures the battery cable to the battery.
5. Connect the battery cable to the system board.
Next steps
1. Install the
base cover.
2. Follow the procedure in After working inside your computer.
Battery cable
Lithium-ion battery precautions
CAUTION:
ā Exercise caution when handling Lithium-ion batteries.
