Using the printer control panel
1
2
3
4
5
6
7
8
9
10
Use the To
1 Display
• View the printer status.
• Set up and operate the printer.
2 Select button Submit changes made in the printer settings.
3 Arrow buttons Scroll up and down or left and right.
4 Keypad Enter numbers, letters, or symbols.
5 Sleep button Enable Sleep mode or Hibernate mode.
Do the following to wake the printer from Sleep mode:
• Press any hard button.
• Pull out Tray 1 or load paper in the multipurpose feeder.
• Open a door or cover.
• Send a print job from the computer.
• Perform a power‑on reset with the main power switch.
• Attach a device to the USB port on the printer.
6 Stop or Cancel button Stop all printer activity.
7 Back button Return to the previous screen.
8 Home button Go to the home screen.
9 Indicator light Check the status of the printer.
10 USB port Connect a flash drive to the printer.
Note: Only the front USB port supports flash drives.
Understanding the colors of the indicator and Sleep button
lights
The colors of the indicator and Sleep button lights on the printer control panel signify a certain printer status or condition.
Learning about the printer 12
