For Macintosh users
1
Open a Web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address on the printer control panel. The IP address appears as four sets of numbers
separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the Web page correctly.
2 Add the printer.
• For IP printing:
a From the Apple menu, navigate to either of the following:
– System Preferences > Print & Scan
– System Preferences > Print & Fax
b Click +.
c Click the IP tab.
d Type the printer IP address in the address field, and then click Add.
• For AppleTalk printing:
Notes:
– Make sure AppleTalk is activated on your printer.
– This feature is supported only in Mac OS X version 10.5.
a From the Apple menu, navigate to:
System Preferences > Print & Fax
b Click +, and then navigate to:
AppleTalk > select the printer > Add
Setting up serial printing
Use serial printing to print even when the computer is far from the printer, or to print at a reduced speed.
After installing the serial or communication (COM) port, configure the printer and the computer. Make sure you have
connected the serial cable to the COM port on your printer.
1 Set the parameters in the printer.
a From the printer control panel, navigate to the menu for the port settings.
b Locate the menu for the serial port settings, and then adjust the settings, if necessary.
c Save the modified settings, and then print a menu settings page.
2 Install the printer driver.
a Insert the Software and Documentation CD.
If the installation dialog does not appear after a minute, then launch the CD manually:
1 Click , or click Start and then click Run.
2 In the Start Search or Run dialog, type D:\setup.exe, where D is the letter of the CD or DVD drive.
3 Press Enter, or click OK.
b Click Install.
c Follow the instructions on the computer screen.
Additional printer setup 41

Table of Contents

Other manuals for Dell B5460dn Mono Laser Printer

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell B5460dn Mono Laser Printer and is the answer not in the manual?

Dell B5460dn Mono Laser Printer Specifications

General IconGeneral
Print TechnologyLaser
Print Resolution1200 x 1200 dpi
Standard Memory512 MB
Output Capacity500 sheets
Processor Speed800 MHz
Weight52.9 lbs
Monthly Duty Cycle275, 000 pages
Input Capacity650 sheets
ConnectivityUSB 2.0, Ethernet
First Page Out Time4.4 seconds
Maximum Paper SizeA4, Legal
Operating System CompatibilityWindows, Linux, Mac OS
Duplex PrintingStandard
