Use To
Feed Direction
Short Edge
Long Edge
Specify the feed direction if the paper can be loaded in either direction.
Notes:
• Short Edge is the factory default setting.
• Long Edge appears only when the longest edge is shorter than the
maximum width supported in the tray.
Bin Setup menu
Use To
Output Bin
Standard Bin
Bin [x]
Specify the default bin.
Notes:
• If multiple bins are assigned the same name, then the
name appears only once in the menu.
• Standard Bin is the factory default setting.
Configure Bins
Mailbox
Link
Mail Overflow
Link Optional
Type Assignment
Specify configuration options for bins.
Notes:
• Mailbox is the factory default setting. This setting
treats each bin as a separate mailbox.
• Link configures all available bins as one large bin.
• Mail Overflow configures each bin as a separate
mailbox.
• Link Optional links all available bins except the
standard bin and only appears when at least two
optional bins are installed.
• Type Assignment assigns each paper type to a bin or
linked bin set.
• Bins assigned the same name are automatically
linked unless Link Optional is selected.
Overflow Bin
Standard Bin
Bin [x]
Specify an alternative bin when a designated bin is full.
Notes:
• Standard Bin is the factory default setting.
• If multiple bins are assigned the same name, then the
name only appears once in the bin list.
• [x] can be any number between 1 and 12 if the
appropriate optional bins are installed.
Understanding printer menus 89
