Dell B5460dn Mono Laser Printer User Manual

Installing a printer hard disk
Note: This task requires a flathead screwdriver.
CAUTION—SHOCK HAZARD: If you are accessing the controller board or installing optional hardware or
memory devices sometime after setting up the printer, then turn the printer off, and unplug the power cord
from the electrical outlet before continuing. If you have any other devices attached to the printer, then turn
them off as well, and unplug any cables going into the printer.
Warning—Potential Damage: Controller board electronic components are easily damaged by static electricity.
Touch something metal on the printer first before touching any controller board electronic components or
connectors.
1 Access the controller board.
For more information, see “Accessing the controller board” on page 14.
2 Unpack the printer hard disk.
3 Locate the appropriate connector on the controller board cage.
Note: If an optional ISP is currently installed, then the printer hard disk must be installed onto the ISP.
Additional printer setup 25

Dell B5460dn Mono Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	512 MB
Output Capacity	500 sheets
Processor Speed	800 MHz
Weight	52.9 lbs
Monthly Duty Cycle	275, 000 pages
Input Capacity	650 sheets
Connectivity	USB 2.0, Ethernet
First Page Out Time	4.4 seconds
Maximum Paper Size	A4, Legal
Operating System Compatibility	Windows, Linux, Mac OS
Duplex Printing	Standard
