Dell B5460dn Mono Laser Printer User Manual

To install a printer hard disk onto the ISP:
a Remove the screws attached to the printer hard disk mounting bracket, and then remove the bracket.
b Align the standoffs of the printer hard disk to the holes in the ISP, and then press the printer hard disk down
until the standoffs are in place.
Installation warning: Hold only the edges of the printed circuit board assembly. Do not touch or press on
the center of the printer hard disk. Doing so may cause damage.
c Insert the plug of the printer hard disk interface cable into the receptacle of the ISP.
Note: The plugs and receptacles are color‑coded.
Additional printer setup 26

Dell B5460dn Mono Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Standard Memory	512 MB
Output Capacity	500 sheets
Processor Speed	800 MHz
Weight	52.9 lbs
Monthly Duty Cycle	275, 000 pages
Input Capacity	650 sheets
Connectivity	USB 2.0, Ethernet
First Page Out Time	4.4 seconds
Maximum Paper Size	A4, Legal
Operating System Compatibility	Windows, Linux, Mac OS
Duplex Printing	Standard
