[x]‑page jam, remove tray 1 to clear duplex. [235–239]
1 Pull out the tray completely.
Note: Lift the tray slightly and pull it out.
2
3
1
2 Push down the front duplex flap, then firmly grasp the jammed paper, and then gently pull the paper to the right
and out of the printer.
Note: Make sure all paper fragments are removed.
2
1
3 Insert the tray.
4 From the printer control panel, select Next > > Clear the jam, press OK > to clear the message and continue
printing.
Clearing jams 162
