Page #42 background imageLoading...
Page #42 background image
d Select Advanced, and then click Continue.
e From the Configure Printer Connection dialog, select a port.
f If the port is not in the list, then click Refresh, or navigate to:
Add port > select a port type > enter the necessary information > OK
g Click Continue > Finish.
3 Set the COM port parameters.
After installing the printer driver, set the serial parameters in the COM port assigned to the printer driver.
Note: Make sure the serial parameters in the COM port match the serial parameters you set in the printer.
a Open Device Manager.
1 Click , or click Start and then click Run.
2 In the Start Search or Run dialog, type devmgmt.msc.
3 Press Enter, or click OK.
b Click + beside “Ports” to expand the list of available ports.
c Rightclick the COM port where you attached the serial cable to your computer (example: COM1), and then
click Properties.
d On the Port Settings tab, set the serial parameters to the same serial parameters set in the printer.
Check the serial heading of the menu settings page for the printer settings.
e Click OK, and then close all the dialogs.
f Print a test page to verify printer installation.
Verifying printer setup
Printing a menu settings page
Print a menu settings page to review the current menu settings and to verify if the printer options are installed correctly.
Note: If you have not changed any menu settings, then the menu settings page lists all the factory default settings.
When you select and save other settings from the menus, they replace the factory default settings as user default
settings. A user default setting remains in effect until you access the menu again, choose another value, and save it.
From the printer control panel, navigate to:
> Settings > >Reports > > Menu Settings Page >
Additional printer setup 42
