20 │ About Your Monitor
Webcam and Microphone Specifications
Model C2423H/C2723H
Lens Field of view 88.9° for 2560 x 1920
Focus mode Fixed Focus
Focus area 35 cm ~ 1.5 m
Focusing distance
(no
rmal mode)
70 cm
Image Sensor Active array size 5 mega-pixel
Video Specification Video frame rate 1920 x 1080 (Full HD)- up
t
o 30 frames per second
Audio Specification Microphone type Digital microphone x 2
Interface USB 2.0 High Speed
Power Supply 3.3 volts +/- 5% for USB and Microphone
5 volts +/- 5% for IR camera
Speaker Specifications
Speaker rated power 2 x 5 W
Frequency Response 200 Hz - 16 kHz
Impedance 8 ohm
NOTE: This monitor is ENERG
Y STAR certified.
This product qualifies for ENERGY STAR in the factory
default settings which can be restored by “Factory Reset”
function in the OSD menu. Changing the factory default
settings or enabling other features may increase power
consumption that could exceed the ENERGY STAR specified
limit.
Model C2423H/C2723H
