Dell C3760dn Color Laser Printer User Manual

164 Dell™ Printer Configuration Web Tool
Va lu es :
Kerberos Server
Purpose:
To specify the settings for the Kerberos server.
Va lu es :
LDAP Server
Purpose:
To specify the settings of the LDAP server.
Va lu es :
LDAP Authentication
Purpose:
To specify the LDAP server authentication method.
Va lu es :
Authentication Type
(for ColorTrack PRO)
Authentication System
Settings
Select the authentication system from the list.
Optional Information Server Response Time-
Out
Sets the amount of time the printer should wait for response from the
server. Sets the time period from 1 to 75 seconds.
Search Time-Out Sets the amount of time the printer should wait for searching for the
server. Sets the time period from 5 to 120 seconds.
Kerberos Server
(for ColorTrack PRO)
IP Address / Host Name
& Port
Sets the IP address or host name, and the port address. The port address
must be 88 or between 5,000 and 65,535.
Domain Name Enter the domain name.
Server Information
(for ColorTrack PRO)
IP Address / Host Name
& Port
Sets IP address or the host name, and the port address. The port address
must be 389, 3268, or between 5,000 and 65,535.
*1
LDAP Server Displays the current software information of the LDAP server.
Optional Information
(for ColorTrack PRO)
Search Directory Root Enters the search directory root.
Login Name Enters the login name.
Password Enters the login password using 1 to 127 alphanumeric characters. If the
password is left blank (NULL), you cannot log in to a server.
Re-enter-Password Enters the login password again to confirm it.
Search
Time-Out
Select Wait LDAP Server Limit to follow the time specified by the LDAP
server. Select Wait to specify the time between 5 and 120 seconds.
*1
When the optional hard disk is installed, 636 and 3269 also can be specified as the port address.
LDAP Authentication
(for ColorTrack PRO)
Authentication Method Shows the authentication method.
Use Added Text String Select whether to use the added text string from the list.
Text String Added to
User Name
Enter the added text string.

Dell C3760dn Color Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Monthly Duty Cycle	Up to 80, 000 pages
Duplex Printing	Yes
Standard Input Capacity	550 sheets
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 inches
Network Ready	Yes
Toner Cartridges	Black, Cyan, Magenta, Yellow
Memory	256 MB
Print Speed	Up to 36 ppm (black) / Up to 36 ppm (color)
