Dell C3760dn Color Laser Printer - Rear View

28 About the Printer
Rear View
1 Control Board 6 Duplex Unit (C3760dn only)
2 Left Side Cover 7 2nd Belt Transfer Roller (2nd BTR)
3 Ethernet Port 8 Fusing Unit
4 Wireless Adapter Socket 9 Power Connector
5 USB Port 10 Rear Cover
1
2
3
4
5
6
7
8
9
10
