344 Maintaining Your Printer
NOTE: If it is difficult to choose only one value, as in the case that there seem to be two values closest to a straight line, take the
value between the two. For example, in the figure above, -6 and -8 are the values closest to a straight line, so you would enter the
value -7.
Slow Scan
On the Chart 2 of the color registration chart, find the medium line within the range of white area for each color
pattern (PY, PM, and PC). If you find the medium line, make a note of the value (-9
to +9) indicated by the
medium line for each color.
When the value is 0 for each color, you do not need to adjust the color registration for the slow scan.
When the value is not 0, enter the value using the procedure in "Entering Values."
Entering Values
When Using the Operator Panel
Using the operator panel, enter the values found in the color registration chart to make adjustments.
1
Press the (Menu) button.
2 Press the button until Admin Settings is highlighted, and then press the (Set) button.
3 Press the button until Maintenance is highlighted, and then press the (Set) button.
4 Press the button until Color Reg Adjust is highlighted, and then press the (Set) button.
5 Press the button until Enter Number is highlighted, and then press the (Set) button.
6 Ensure that LY is highlighted and press the or button to specify the values.
7 Press the button to move the highlight to the next value.
8 Press the (Set) button.
RY is highlighted.
9 Repeat steps 6 to 8 to enter the desired values, and then press the (Set) button.
Lattice pattern

Dell C3760dn Color Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Monthly Duty Cycle	Up to 80, 000 pages
Duplex Printing	Yes
Standard Input Capacity	550 sheets
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 inches
Network Ready	Yes
Toner Cartridges	Black, Cyan, Magenta, Yellow
Memory	256 MB
Print Speed	Up to 36 ppm (black) / Up to 36 ppm (color)
