Dell C3760dn Color Laser Printer User Manual

342 Maintaining Your Printer
Adjusting Color Registration
To adjust the color registration when you first install the printer or after moving it to a new location, follow the
procedure below.
• Printing the Color Registration Chart
• Determining Values
• Entering Values
NOTE: If the Panel Lock Control is set to Enable, you need to enter the four digit password to enter the Admin
Settings menu.
Printing the Color Registration Chart
When Using the Operator Panel
1 Press the (Menu) button.
2 Press the button until Admin Settings is highlighted, and then press the (Set) button.
3 Press the button until Maintenance is highlighted, and then press the (Set) button.
4 Press the button until Color Reg Adjust is highlighted, and then press the (Set) button.
5 Press the button until Color Regi Chart is highlighted, and then press the (Set) button.
6 Press the button until Yes is highlighted, and then press the (Set) button.
The color registration chart is printed.
When Using the Tool Box
1 Click Start → All Programs → Dell Printers → Dell C3760 Color Laser Printer → Tool Box .
NOTE: For details about starting the Tool Box, see "Starting the Tool Box."
The Tool Box opens.
2 Click the Printer Maintenance tab.
3 Select Maintenance from the list at the left side of the page.
The
Maintenance page is displayed.
4 Click Start next to Print Color Regi Chart under Color Registration Adjustments .
The color registration chart is printed.
Determining Values
On the color registration chart, there are two types of charts: Chart 1 (fast scan) and Chart 2 (slow scan).

Dell C3760dn Color Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Monthly Duty Cycle	Up to 80, 000 pages
Duplex Printing	Yes
Standard Input Capacity	550 sheets
Connectivity	USB 2.0, Ethernet
Maximum Paper Size	8.5 x 14 inches
Network Ready	Yes
Toner Cartridges	Black, Cyan, Magenta, Yellow
Memory	256 MB
Print Speed	Up to 36 ppm (black) / Up to 36 ppm (color)
