Understanding the Tool Box Menus 185
Diagnosis
The Diagnosis tab includes the Chart Print and Environment Sensor Info pages.
Chart Print
Purpose:
To print various charts that can be used for diagnosis of the printer. The chart is printed to A4 or letter size paper.
Va lu es :
Environment Sensor Info
Purpose:
To print the internal environment sensor information of the printer to Result.
Va lu es :
Resetting Defaults
After executing this function and rebooting the printer, the menu parameters are reset to their default values.
The following menu parameters are exceptions and are not reset.
• Network settings
• Panel Lock settings and password
• Function Enabled settings and passwords
• Login Error settings
• Set Available Time settings
• Secure Job Expiration settings
• USB Port settings
• Data Encryption settings
• Hard Disk Over write settings
• ColorTrack Mode settings
• ColorTrack Error Report settings
• Non Registered User settings
Pitch Configuration Chart Prints full halftone pages for yellow, magenta, cyan, and black. Also prints pages to
check the pitch. A total of five pages are output.
Ghost Configuration Chart Prints a chart to check for ghost printing. One page is printed.
4 Colors Configuration Chart Bands of yellow, magenta, cyan, and black are printed with varying density. One
page is printed.
Banding Detection Chart Prints charts to check which color the banding occurred and the distance between
each band.
MQ Chart Prints charts to check for the banding in A4 or Letter.
Alignment Chart Prints a chart to check for proper alignment of the print image on the paper. One
page is printed.
Get Environment Sensor
Info
Click this button to confirm the internal environment sensor information of the printer such as
temperature and humidity.
