Troubleshooting Guide 389
MPF Misfeed Jam
Action Yes No
1 Ensure that the MPF is properly inserted.
Does this solve your problem?
The task is complete. Proceed to the action
corresponding to the
type of the print media
being used:
•Thick - 2a
• Thin - 2b
•Coated - 2c
•Envelope - 2d
If performing manual
duplex printing, go to
action 2e.
If using paper other
than the above or if not
performing manual
duplex printing, go to
action 2f.
2a Use thick paper that is 216 g/m
2
or less.
Does this solve your problem?
The task is complete. Go to action 3a.
2b Use thin paper that is 60 g/m
2
or more.
Does this solve your problem?
The task is complete. Go to action 3a.
2c Load coated paper one sheet at a time.
Does this solve your problem?
The task is complete. Go to action 3b.
2d Ensure that the envelope is properly loaded in the MPF as instructed in
"Loading an Envelope in the MPF."
Does this solve your problem?
The task is complete. Go to action 3c.
2e Ensure that the print media is not curled. The task is complete. Go to action 3a.
2f Is the print media damp? Go to action 3d. Go to action 3a.
3a Fan the print media.
Does this solve your problem?
The task is complete. Go to action 3b.
3b Wipe the retard roller in the MPF with a cloth moistened with water.
Does this solve your problem?
The task is complete. Go to action 4b.
3c If the envelope is deformed, correct it or use another envelope.
Does this solve your problem?
The task is complete. Go to action 3a.
3d Turn over the print media.
Does this solve your problem?
The task is complete. Go to action 4a.
4a Use print media that is not damp.
Does this solve your problem?
The task is complete. Go to action 3a.
4b Replace the drum cartridges.
Does this solve your problem?
The task is complete. Contact Dell.
