392 Troubleshooting Guide
2 Replace the transfer belt unit, the 2nd BTR, and the retard roller.
a
Replace the transfer belt unit, the 2nd BTR, and the retard roller. See
"Replacing the Transfer Belt Unit, the 2nd Belt Transfer Roller (2nd
BTR), and the Retard Roller."
b
After you replace the transfer belt unit, the 2nd BTR,
and the retard
roller
, click
Chart Print
on the
Diagnosis
tab.
c
Click
Pitch Configuration Chart
.
The Pitch Configuration Chart is printed.
Does this solve your problem?
The task is complete. Go to action 3.
3 Replace the fusing unit.
a
Replace the fusing unit. See "Replacing the Fusing Unit."
b
After you replace the fusing unit, click
Chart Print
on the
Diagnosis
tab.
c
Click
Pitch Configuration Chart
.
The Pitch Configuration Chart is printed.
Does this solve your problem?
The task is complete. Go to action 4.
4 Replace the waste toner box.
Does this solve your problem?
The task is complete. Go to action 5.
5 Replace the drum cartridges.
Does this solve your problem?
The task is complete. Go to action 6.
6 Replace the toner cartridge (K). See "Replacing the Toner Cartridges." The task is complete.
(The toner cartridge
(K) you are using has
been damaged. Replace
it with a new one.)
Go to action 7.
7 Replace the toner cartridge (Y). See "Replacing the Toner Cartridges." The task is complete.
(The toner cartridge
(Y) you are using has
been damaged. Replace
it with a new one.)
Go to action 8.
8 Replace the toner cartridge (M). See "Replacing the Toner Cartridges." The task is complete.
(The toner cartridge
(M) you are using has
been damaged. Replace
it with a new one.)
Go to action 9.
