Dell C3765dnf Color Laser Printer User Manual

Removing Options 509
Removing the Optional Wireless Adapter
WARNING: When you remove the optional wireless adapter, be sure to turn off the printer, unplug the power cable, and
disconnect all cables from the back of the printer before starting these tasks.
1 Ensure that the printer is turned off.
2 Turn the screw on the left side cover counterclockwise to remove it.
3 Slide the left side cover towards the back of the printer.
4 Open the left side cover completely.

Dell C3765dnf Color Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
Display	4.3-inch color touch screen
Memory (Maximum)	512 MB
Fax	Yes
Maximum Paper Size	8.5 x 14 inches
Connectivity	USB, Ethernet
Paper Input Capacity	150-sheet multipurpose tray
Scanner Type	Flatbed, ADF
Scan Resolution	Up to 600 x 600 dpi
Mobile Printing	Dell Mobile Print
Print Speed	Up to 36 ppm (black/color)
