Dell C3765dnf Color Laser Printer User Manual

Troubleshooting Guide 541
Fog
Bead-Carry-Out (BCO)
Action Yes No
1 Check the light fatigue pattern using the Pitch Configuration Chart.
a Launch the Tool Box , and click Chart Print on the Diagnosis tab.
b Click Pitch Configuration Chart .
The Pitch Configuration Chart is printed.
Does the pattern on the output match with that on the Pitch
Configuration Chart?
Go to action 2. Contact Dell.
2 Replace the drum cartridges. See "Replacing the Drum Cartridges."
Does this solve your problem?
The task is complete. Contact Dell.
Action Yes No
1 Replace the drum cartridges.
a Replace the drum cartridges. See "Replacing the Drum Cartridges."
b After you replace the drum cartridges, click Chart Print on the
Diagnosis tab.
c Click 4 Colors Configuration Chart .
The 4 Colors Configuration Chart is printed.
Does this solve your problem?
The task is complete. Contact Dell.

Dell C3765dnf Color Laser Printer Specifications

General

Print Technology	Laser
Print Resolution	600 x 600 dpi
Duplex Printing	Yes
Monthly Duty Cycle	Up to 80, 000 pages
Display	4.3-inch color touch screen
Memory (Maximum)	512 MB
Fax	Yes
Maximum Paper Size	8.5 x 14 inches
Connectivity	USB, Ethernet
Paper Input Capacity	150-sheet multipurpose tray
Scanner Type	Flatbed, ADF
Scan Resolution	Up to 600 x 600 dpi
Mobile Printing	Dell Mobile Print
Print Speed	Up to 36 ppm (black/color)
