Steps
1. Align the tabs on the left-side cover with the slots on the chassis.
2. Slide it towards the front of the computer until the release latch locks the side cover.
Next steps
1. Follow the procedure in After working inside your computer.
Front cover
Removing the front cover
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the left-side cover.
About this task
The following images indicate the location of the front cover and provide a visual representation of the removal procedure.
Steps
1. Place the computer in an upright position.
2. Gently pry and release the front-cover tabs sequentially from the top.
3. Move the front cover outward from the chassis.
14
Disassembly and reassembly
