Installing the optional internal dual SD module
Prerequisites
CAUTION: Many repairs may only be done by a certified service technician. You should only
perform troubleshooting and simple repairs as authorized in your product documentation, or as
directed by the online or telephone service and support team. Damage due to servicing that is
not authorized by Dell is not covered by your warranty. Read and follow the safety instructions
that are shipped with your product.
1. Follow the safety guidelines listed in the Safety instructions section.
2. Follow the procedure listed in the Before working inside your system section.
NOTE: Temporarily label each SD card with its corresponding slot before removal.
Steps
1. Locate the internal dual SD module (IDSDM) connector on the system board. To locate the IDSDM
connector, see the System board connectors section.
2. Align the IDSDM with the connector on the system board.
3. Push the IDSDM until it is firmly seated on the system board.
Next steps
1. Install the SD cards.
NOTE: Re-install the SD cards into the same slots based on the labels you had marked on the
cards during removal.
2. Follow the procedure listed in the After working inside your system section.
Related Links
Safety instructions
Before working inside your system
Installing an internal SD card
After working inside your system
GUID-19FB9DD2-7038-4746-8AFB-92883961211F
Network daughter card
The Network daughter card (NDC) is a small, removable mezzanine card. The NDC provides you with the
flexibility of choosing different network connectivity options, for example—4 x 1GbE, 2 x 10GbE and 2 x
Converged Network Adapter.
