Option Description
System CPLD
Version
Specifies the current version of the system complex programmable logic device
(CPLD) firmware.
UEFI Compliance
Version
Specifies the UEFI compliance level of the system firmware.
Related Links
System Information
System Information details
Viewing System Information
GUID-4AC544B8-6044-49A0-BA0B-3B10EFAAD1D8
Memory Settings
You can use the Memory Settings screen to view all the memory settings and enable or disable specific
memory functions, such as system memory testing and node interleaving.
Related Links
Memory Settings details
System BIOS
Viewing Memory Settings
GUID-C7F63EB3-866A-4831-A062-244E1B0E038F
Viewing Memory Settings
To view the Memory Settings screen, perform the following steps:
1. Turn on, or restart your system.
2. Press F2 immediately after you see the following message:
F2 = System Setup
NOTE: If your operating system begins to load before you press F2, wait for the system to finish
booting, and then restart your system and try again.
3. On the System Setup Main Menu screen, click System BIOS.
4. On the System BIOS screen, click Memory Settings.
Related Links
Memory Settings
Memory Settings details
GUID-3A2FD360-F145-4F49-8115-EE4BCCB336D1
Memory Settings details
The Memory Settings screen details are explained as follows:
Option
Description
System Memory
Size
Specifies the memory size in the system.
System Memory
Type
Specifies the type of memory installed in the system.
System Memory
Speed
Specifies the system memory speed.
