Dell E2014T User Manual

72% (CIE1976)
Color gamut (typical)
NOTE: Color gamut (typical) is based on CIE1976
(72%) and CIE1931 (72%) test standards.
Touch
Type Infrared Optical System
Panel diagonal 19.5”
Panel thickness 6.5 ± 0.3 mm
Active area Extended beyond viewing area
Cover glass thickness 3.0 +0.0/-0.3 mm
Input method Bare finger, thin gloves, conductive stylus
Touch point 5 touches with palm accommodation
Output position resolution 32767 x 32767
Touch method Fingers and thin gloves
Operating system Windows 8 certified
NOTE: When the monitor is in Sleep mode, move the mouse, press any key on
the keyboard, or double-tap firmly on the screen to wake up the monitor.
Resolution
Horizontal scan range 30 kHz to 83 kHz (automatic)
Vertical scan range 56 Hz to 75 Hz (automatic)
Maximum resolution 1600 x 900 at 60 Hz
Video display capabilities 480p, 576p, 720p, 1080p, and 1080i
Electrical
Video input signals DisplayPort 1.2 / HDMI / MHL / VGA
• Separate horizontal and vertical
synchronizations.
Synchronization input signals
• Polarity-free TTL level
• SOG (composite SYNC on green)
AC input voltage 100 VAC to 240 VAC
Frequency 50 Hz or 60 Hz + 3 Hz
Current 1.5 A (Max.)
120 V:70 A (Max.)
Inrush current
240 V:150 A (Max.)
About Your Monitor  11

Dell E2014T Specifications

General

Pixel pitch	0.27 x 0.27 mm
Aspect ratio	16:9
Screen shape	Flat
Response time	2 ms
Display diagonal	19.5 \
Touchscreen type	Tabletop
Display brightness	225 cd/m²
Display resolution	1600 x 900 pixels
Display technology	LED
Viewing angle, vertical	160 °
Contrast ratio (dynamic)	8000000:1
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	49.4 cm
Viewing angle, horizontal	170 °
Certification	EPEAT Gold\\r TCO
Product color	Black
Display viewable area (HxV)	432.00 x 432.00 mm
Dimensions (W x D x H) with stand	505.9 x 165 x 376 mm
Cables included	AC, HDMI, USB
Tilt angle range	5 - 31 °
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	16 W
USB upstream port type	USB Type-B
USB Type-A downstream ports quantity	2
Package weight	6070 g
Sustainability certificates	ENERGY STAR
NVIDIA G-SYNC	No

Weight and Dimensions

Depth (with stand)	165 mm
Width (with stand)	505.9 mm
Height (with stand)	376 mm
Weight (with stand)	4890 g
Depth (without stand)	51.7 mm
Height (without stand)	311.2 mm
Weight (without stand)	3430 g
