Table 19. Riser configuration (include slots 1 and 3)
Card type Slot priority Maximum number of cards
Broadcom (25 G DP) 3 1
Intel 10 G (BaseT DP) 3 1
Intel 10 G (SFP+ DP) 3 1
Intel 1 G (QP) 3 1
Intel 25 G (SFP DP) 3 1
Emulex (FC32 2P/1P) 3 1
Emulex (FC16 1P)/(FC16 2P) 3 1
Mellanox 100 G (CX5/CX6 H100) 3 1
Mellanox 25 G (CX4LX DP/CX5 DP) 3 1
Qlogic (HBA FC32 SP/DP) 3 1
Qlogic (HBA FC16 SP/DP) 3 1
Qlogic 10 G (SFP DP) 3 1
Qlogic 25 G ( BaseT DP) 3 1
Internal storage (BOSS) 3 1
Nvidia T4 GPGPU 3 1
Solarflare 25 G (SFP DP) 3 1
LOM Riser ( 2x1 G)/(2x10 G)/(2x25 G) 1 1
Table 20. Riser configuration (include slots 1, 2, and 3)
Card type Slot priority Maximum number of cards
PERC 9: Mini mono (H730P/H330) Integrated slot 1
PERC 10: Mini mono (H740P) Integrated slot 1
HBA: Mini mono (HBA330) Integrated slot 1
PERC 10: External adapter (H840) 3, 2 2
PERC 10: External adapter (H840) (FH
or LP)
3, 2 2
PERC 11: External adapter (HBA355E) 3, 2 2
HBA: External adapter 3, 2 2
NVME PCIE SSD 3, 2 2
Broadcom (1 G DP/1G QP) 3, 2 2
Broadcom (10 G DP) 3, 2 2
Broadcom (25 G DP) 3, 2 2
Intel 10 G (BaseT DP) 3, 2 2
Intel 10 G (SFP+ DP) 3, 2 2
Intel 1 G (QP) 3, 2 2
Intel 25 G (SFP DP) 3, 2 2
Emulex (FC32 2P/1P) 3, 2 2
Emulex (FC16 1P)/(FC16 2P) 3, 2 2
