Dell EMC PowerEdge R240 User Manual

Figure 16. Installing the fan blank
Next steps
1. Follow the procedure listed in the After working inside your system.
Removing a cooling fan
Prerequisites
WARNING:
Opening or removing the system cover when the system is on may expose you to a risk of electric shock.
Exercise utmost care while removing or installing fans.
1. Follow the safety guidelines listed in Safety instructions.
2. Follow the procedure listed in Before working inside your system.
3. Remove the air shroud.
Steps
1. Press the release tabs on the fan cable connector and disconnect it from the connector on the system board.
2. Lift the fan out of the fan cage.
Figure 17. Removing a cooling fan
42
PowerEdge R240 installing and removing system components

Dell EMC PowerEdge R240 Specifications

General

Processor Sockets	1
Memory	Up to 64GB DDR4 ECC UDIMM
Memory Slots	4
Chipset	Intel C246
Form Factor	1U Rack
Processor	Intel Xeon E-2100
Storage	Up to 4 x 3.5" SAS/SATA (HDD/SSD) or 2.5" SAS/SATA (HDD/SSD)
RAID Support	PERC H330
Network Interface	2 x 1GbE LOM
Power Supply	350W
Operating System	Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, VMware ESXi
Management	iDRAC9
Memory Speed	2666 MT/s
Maximum internal storage	Up to 48TB (with 12TB drives)
