Dell EMC PowerEdge R7515 - Page 70

Table 19. Riser configurations: Riser 1A + Riser 2 – CPU
Card type Slot priority Maximum number of cards
LOM riser ; 2x10G BCM57416 (BASeT/
SFP+)
1 1
LOM riser ; 2x25G (Broadcom) 1 1
NVMe PCIe SSD 2, 3 2
Mellanox 100G (CX5/CX6 H100) 3, 2 2
Mellanox 25G (CX4LX DP/CX5 DP) 2, 3 2
Emulex (FC32 SP/DP) 3, 2 2
Emulex (FC16 SP/DP) 2, 3 2
Qlogic (HBA FC32 SP/DP) 3, 2 2
Qlogic (HBA FC16 SP/DP) 2, 3 2
Qlogic 10G (SFP DP) 2, 3 2
Qlogic 25G ( BaseT DP) 2, 3 2
Solarflare 25G (SFP DP) 2, 3 2
Intel 10G ( BaseT DP) 2, 3 2
Intel 10G (SFP+ DP) 2, 3 2
Intel 1G (QP) 2, 3 2
Intel 25G SFP DP 2, 3 2
Broadcom 1G (QP) 2, 3 2
Broadcom 10G ( BaseT DP) 2, 3 2
Broadcom 25G (SFP DP) 2, 3 2
PERC 10: External adapter (Dell) 2, 3 1
HBA: External adapter (Dell) 2, 3 1
Internal storage (BOSS) 2, 3 1
PERC 9: Mini mono (H730P/H330) Integrated slot 1
PERC 10: Mini mono (H740P) Integrated slot 1
HBA: Mini mono (HBA330) Integrated slot 1
PERC 10: External adapter (H840) 2, 3 2
HBA: External adapter 2, 3 2
Table 20. Riser configurations: Riser 1B – CPU
Card type Slot priority Maximum number of cards
LOM riser ; 2x1G BCM5720L 1 1
LOM riser ; 2x10G BCM57416 (BASeT/
SFP+)
1 1
LOM riser ; 2x25G (Broadcom) 1 1
FPGA: XILINX FH 3 1
GPU: Nvidia T4 16GB (FH) 2, 3 2
GPU: Nvidia V100S 32GB 3 1
Intel 10G (BaseT DP FH) 2, 3 2
70 Installing and removing system components
