n
RAM displays the node’s RAM capacity, inventory, size, speed, temperature
and number of errors according to each DIMM slot. NVDIMM Battery
Properties shows the health and state of the NVDIMM's onboard battery.
n
Controller shows RAID storage controller properties, such as inventory,
temperature, specifications, IDs, battery, and bus location in the node
n
PSU (power supply unit) displays the state and input of the node’s PSUs
n
Node displays inventory details, IP addresses and roles, DNS and NTP IP
addresses, boot disk information, temperature and voltage readings at a
number of physical locations in the node, and air flow.
n
Cache displays information about the caching used in the node, such as cache
size, a list of the devices being used to cache data, and a list of the HDDs being
cached
n
Physical drives (devices) each display location, inventory, specifications,
temperature and other health statuses, endurance (where relevant),
configuration, and logical drive properties. Acceleration properties for the
selected device are also shown here, in the Logical Drive Properties section of
this Property Sheet.
You can view properties for multiple objects by using the Duplicate property sheet to
a new window button, and then navigating to a different object’s row in the table.
When more than one property sheet is open, a floating widget that controls them is
displayed in the bottom part of the main window, as shown in the following figure.
Note:
You can open property sheets, duplicate them, and then simultaneously
work on other unrelated objects in the system.
Figure 24 Multiple floating Property Sheets
21
3
4
VxFlex OS GUI Features
Dell EMC VxFlex Ready Node AMS User Guide 107
