A–1
A Environmental, Power, and Other Specifications
Table A-2 describes the environmental, power, and physical specifications for a
PS6010 array.
Table A-2: PS6010 Array Specifications
Component Requirement
Weight of fully-loaded array 35 kg (77.6 lb)
Operating temperature 5 to 35 °C (41 to 95 °F)
Storage temperature -30 to 60 °C (-22 to 140 °F)
Maximum operating altitude 3048 meters (10,000 feet)
Operational relative humidity 20% to 80% noncondensing
Storage relative humidity 5% to 80% noncondensing
Thermal output (fully-loaded array) 1800 BTU/hour (SAS disks)
1650 BTU/hour (SATA disks)
Operational shock 5g peak 1/2 sin, for 10ms
Operational vibration .21 G
rms
5 to 500 Hz Random
Input voltage 100 to 240 VAC (auto-sensing)
Input frequency 48 - 62 Hz
System input power 560 VA (maximum)
Each power supply 450 watts DC output
Maximum input power: 0.7 KVA
Input current: 7 – 3.5A
Chassis dimensions 13 cm by 48.26 cm by 55.1 cm
(5.12 in. by 19 in. by 21.7 in.)
