Dell Force10 MXL Blade Getting Started Guide

10 Hardware Overview
USB Ports
Figure 1-3. USB Ports on Front Panel
Use the lower USB console port to configure the switch through an RS-232
serial interface (Figure 1-3). This port provides a direct connection to the
switch and allows you to access the command line interface (CLI) from a
console terminal connected to the port through the provided serial cable
(with USB type-A to female DB-9 connectors).
The console port supports asynchronous data of eight data bits, one stop bit,
no parity bit, and no flow control. The default baud rate is 9600 bps.
The upper USB port functions as an external flash drive that you can use to
store configuration files and scripts.
USB Console Port
USB Storage Port

Dell Force10 MXL Blade Specifications

General

Switching Capacity	1.28 Tbps
Forwarding Rate	952 Mpps
Product Type	Blade Switch
Latency	< 3 microseconds
Operating Temperature	0°C to 40°C (32°F to 104°F)
Redundancy	Yes
Management	CLI, SNMP, Web
Layer Support	Layer 2, Layer 3
Jumbo Frame Support	Up to 9216 bytes
Management Ports	1 x 10/100/1000 Mbps
Storage Temperature	-40°C to 70°C
Weight	4.5 kg (9.9 lbs)
