Dell Force10 MXL Blade Getting Started Guide

Technical Specifications 35
Power Requirements
IEEE Standards
The MXL 10/40GbE Switch complies with the following IEEE standards:
• 802.1AB LLDP
• 802.1ag Connectivity fault Management
• 802.1D Bridging, STP
• 802.1p L2 Prioritization
• 802.1Q VLAN Tagging, Double VLAN Tagging, GVRP
• 802.1s MSTP
• 802.1w RSTP
• 802.3ab Gigabit Ethernet (1000BASE-T)
• 802.3ac Frame Extensions for VLAN Tagging
• 802.3ad Link Aggregation with LACP
• 802.3ae 10 Gigabit Ethernet (10GBASE-X)
• 802.3ba 40 Gigabit Ethernet (40GBase-SR4, 40GBase-CR4) on optical
ports
• 802.3u Fast Ethernet (100BASE-TX)
• 802.3x Flow Control
• 802.3z Gigabit Ethernet (1000BASE-X)
• ANSI/TIA-1057 LLDP-MED
•Force10 PVST+
•MTU 12K bytes
Parameter Specifications
Power supply 100–240 VAC 50/60 Hz
Maximum current draw per system 2 A @ 100/120 VAC
1 A @ 200/40 VAC
Maximum power consumption 123 Watts
Reliability MTBF 355,178 hours

Dell Force10 MXL Blade Specifications

General

Switching Capacity	1.28 Tbps
Forwarding Rate	952 Mpps
Product Type	Blade Switch
Latency	< 3 microseconds
Operating Temperature	0°C to 40°C (32°F to 104°F)
Redundancy	Yes
Management	CLI, SNMP, Web
Layer Support	Layer 2, Layer 3
Jumbo Frame Support	Up to 9216 bytes
Management Ports	1 x 10/100/1000 Mbps
Storage Temperature	-40°C to 70°C
Weight	4.5 kg (9.9 lbs)
